Description
The Atlas 546 is an HO Code 83 left-hand 22-inch radius Snap-Switch remote turnout — the wide-radius remote-throw Snap-Switch for mainline 6-axle and long-passenger operation. Pairs with Atlas 545 (RH 22" manual) and Atlas 544 (LH 22" manual) for a complete 22" Snap-Switch family.
Geometry. 22" radius diverging route exactly matched to Atlas 535 (22" curve) and Atlas 537 (22" 1/3 section). A 1/3 22" radius section is pre-attached to the curved leg so the exit equals a full 22" arc when joined to standard track. Plastic insulated frog — no short-circuit risk, no powered-frog wiring.
Remote switch machine is built into the turnout housing — twin-coil solenoid throws on a momentary pulse. Wire to a panel toggle, Atlas 56 Switch Control Box, or DCC stationary decoder.
Specifications
- Scale: HO
- Rail Code: Code 83 nickel-silver
- Type: Snap-Switch turnout, remote-throw
- Direction: Left Hand
- Diverging Radius: 22"
- Frog: Plastic (insulated)
- Brand: Atlas
- SKU / Item Number: 546
Pairs Well With
- Atlas 545 — RH 22" Snap-Switch manual
- Atlas 544 — LH 22" Snap-Switch manual
- Atlas 535 — 22" radius curve (6pc)
- Atlas 56 — Switch Control Box for panel control
