Description
The Atlas 52 is an HO scale Left Hand remote-actuated snap-switch turnout in the Atlas Code 100 sectional line. A low-profile twin-coil switch motor is built into the turnout base; activate it with a momentary 16V AC pulse via the Atlas Selector, Snap-Relay, or any compatible accessory controller. The diverging route uses Atlas's standard snap geometry — equivalent to an 18″ radius curve — so it drops directly into any standard Atlas Code 100 sectional layout.
Key Features
- Built-in low-profile 16V AC twin-coil switch motor
- Code 100 nickel-silver rail on simulated brown wood ties
- Power-routing frog
- NMRA wheel-flange profile
- Drop-in compatible with all Atlas Code 100 sectional pieces
Specifications
- Scale: HO
- Rail Code: Code 100
- Type: Snap-Switch Turnout (powered)
- Direction: Left Hand
- Operation: Remote (16V AC pulse)
- Diverging radius: 18″ (Atlas standard)
- Brand: Atlas
- SKU: 52
Drive multiple turnouts from a single button via the Atlas Snap-Relay accessory. Compare with the Code 83 True-Track equivalents #480/#481 (powered, with integrated roadbed) and Code 83 Custom-Line #505/#506 #6 turnouts for main-line use.
